used hose crimping machine

FOB Reference Price:Get Latest Price
US $2,300-3,900 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
BNTFLEX
Model Number:
BNT50D
Voltage:
380V/220V/415V
Power(W):
3kw
Dimension(L*W*H):
1070mm*640mm*1150mm
Weight:
320kg
Certification:
CE
Warranty:
3 years
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
crimping machine for hydraulic pipes
Crimping Range:
1/4"to2"
Free Dies:
10 sets
Max opening (mm):
114mm
Rated pressure:
26MPa / 31.5MPa (Optional)
Ruler precision:
0.01mm
The largest crimping pressure:
500T
Work Efficiency:
200 assemblies in 1 hour in auto mode
CONDITIONS AND TERMS:
CNF,,FOB OR DDU,CIF,ETC
SupplyAbility
SupplyAbility:
500 Set/Sets per Year
Packaging & Delivery
Packaging Details
manual hydraulic hose crimping machine:new strong wooden case.
Port
xinggang,tianjin or nigbo, qingdao, shanghai, guangzhou,etc.
Lead Time :
Shipped in 10 days after payment
Hot Selling

BNT50

Hose crimping machine

BNTS350B

Hose cutting machine

BNT65D

Hose skiving machine

Hose ferrule


Hose fitting


Hydraulic hose


2018 BARNETT 2inch hose crimping machine BNT50D made in China
Product Description

Product Application


Automatic GradeAutomatic Machine Type Hose/Pipe Crimping Machine,Crimping Machine, Cable Crimping Machine -Power Source Hydraulic , Electric, Mechanical -Machine Structure Horizontal.A ISO 9001:2008 COMPANY :Tianjin Barnett Trade Co.,Ltd.BNT50D Hose-Crimper is the special machine, you can crimp all types of connectors on the hoses stably and accurately under hydraulic force 500 ton also specially designed for earth moving machines. Compared with other machines, avail in India our model BNT50D Hose Crimping has the characteristic such as, better connecting quality, more quick swaging speed, higher efficiency, easier to manipulate, more enduring, more convenient to maintain and etc. Hose connectors of different diameters all can be swagged only one time; the connector swagged looks smooth and fine, and has large tensile strength and compressive strength. In a word, the crimper is an ideal machine for hose connector assembly factory and for hydraulic.

EXTRA FEATURE : THIS MACHINE CRIMP LOW PRESSURE HOSE LIKE- DIESEL PIPES, AC HOSES, BRAKE HOSE, RUBBER PIPES AND MANY MORE WITH ADDITIONAL DIE SETS AVAILABEL AT EXTRA COST.

Technical Specification

1.Crimping Range (Hose Inner Diameter) : φ6~φ51mm or 1/4" to 2"
2. Max opening (mm): 114 mm
3. Free Dies:10 Sets of dies
4.Item No. of dies:15.19.23.26 length 60mm
                                 31.36.41 length 70mm

                                47.55.60 length 80mm
5.Ruler precision:0.01mm
6. Rated pressure: 26MPa / 31.5MPa (Optional)
7.Volume of oil tank:2.5L / 5L / 10L (Optional)
8. The largest crimping pressure: 500T
9. Double Solenoid valve 24 volts D. C
10. Machines is designed looks stylish table type & panel of the machine is 24 volts D. C that will gives it longer life for any electric faults.
11.Motor Power (as your requirements):3kW / 4kW 1 2 3 phase
12.Voltage (as your requirements):220V-415V 50/60Hz
13. Dimension: 1070*640*1150 mm
14. Gross weight: 320kg
15. 200 assemblies in 1 hour in auto mode
16. Oil tank: Add 46 # hydraulic oil, be sure to add at least half of the original packaging hydraulic oil level gauge.
17. This machine main feature is its production capacity that will make this machine leader in his class
18. Piston, Cylinder, All Dies & Parent Jaws are Wire cut after Hardening and Grinding.
19. No need to operates this machine any skilled labour our machines are Eco friendly & very simple & easy to use.

SPECIFICATIONS FOR 51MM HOSE CRIMPING MACHINE
Product Name
hose crimping and skiving combined type machine
Model
BNT-50D(Electric crimping)
Crimp force
500T
Crimp range (hose Inner Diameter)
φ6mm—φ51mm (1/4''~2'')
Voltage
220V-415V 50/60Hz or  as your requirements
Free Dies
10set dies
Item No. of dies
15.19.23.26 length 60mm
31.36.41 length 70mm
47.55.60 length 80mm
Ruler precision
0.01mm
Volume of oil tank
2.5L / 5L / 10L (Optional)
 Rated pressure
26MPa / 31.5MPa (Optional)
Motor Power
3kW / 4kW 1 2 3 phase(as your requirements)
Voltage
220V-415V 50/60Hz  (as your requirements)
The largest crimping pressure
500T
Work efficiency
200 assemblies in 1 hour in auto mode
Max opening (mm)
114mm
The max open tolerance
± 30mm
Control system
Electric Automatic
Control model
Micro control with Button control with pedal
Dimension
1070*640*1150 mm
Gross weight
320kg

The price and following detail just are for 2inch hose crimping machine BNT50D. If you need the big diameter machine like 3-14inch, please contact us, we will send the information to you.

Our machine can crimp below stuffs,and if you have other shape stuff to crimp, you can send us the details or your products sample,we will provide you with products tailored to the machine and mold.finn power p20 hose crimping machine

Our Company

BNTFLEX was born in 2000 with the sole purpose to supply the best machines and best quality service to the hose production market. Over 17 years of engineering experience have been put into the robust machine designs giving the Best Return on Investment for BNTFLEX customers. BNTFLEX are still a young company and we will continue to listen and work tirelessly to support all existing, old and new customers in the market.
We will take BNTFLEX machines to the market and make BNTFLEX more accessible as we have 100% confidence that once a customer uses BNTFLEX, they will remain with BNTFLEX for life.
Our company were established in Tianjin,China. In the coming years we will continue with our ambitious plans to further expand.
We only work with the best and most reliable products. We understand hose production and we understand hose production equipment.

Our customers
Our hose crimper

THE BNTFLEX HYDRAULIC HOSE CRIMPER AND HOSE SWAGING MACHINES RANGE

BNTFLEX are the global leaders in the manufacturing of quality hose crimping tools. Our Hydraulic Hose Crimper Machines are world renown as the most reliable and accurate Crimping Machine / Swaging Machine on the market. The unique features start with the BNTFLEX non grease system, the fixed 6’o clock die on production machines, stand alone machines, thin crimping heads and quiet swaging machine motors, all give BNTFLEX the hard earned reputation. BNTFLEX detail and design is guaranteed to make huge positive differences to your hose production.

Main Products

Name: our hose crimping machine

Brand: BNTFLEX

Original: China

BNTFLEX HOSE CRIMPING MACHINE SERVICE
BNTflex service hydraulic hose crimpers and swaging tools incorporate the unique BNTflex grease free slide bearing technology, with strong, versatile and lightweight design to give a reliable and inexpensive hose swaging tool service solution. – They are 12 Volt Crimping Machine and 12 Volt Swaging Machine.

Main productss

Name:  our hose crimping machine
Brand: BNTFLEX
Original: China
WORKSHOP CRIMPING MACHINES
BNTFLEX hydraulic hose workshop crimping machines / swaging tools offers professional workshop’s with a reliable range of tools to allow assembly of a variety of hose assemblies.BNTFLEX are the leading solution for flexible workshop hose crimpers which do not compromise on technology. Also 24 Volt Crimping Machine, 24 Volt Swaging Machines, 12 Volt Crimping Machine and 12 Volt Swaging Machine are available for mobile service vehicles.

Machine Products

Name:  our hose crimping machine
Brand: BNTFLEX
Original: China
LEAN PRODUCTION AND SWAGING TOOLS
BNTFLEX lean production hose crimpers and swaging tools are the proven fastest production machines on the China market. User friendly, consistent, unique grease free slide bearing technology and a fixed 6 o’clock die are just some of the reasons why all serious production companies choose BNTFLEX Crimpers.

Main Product

Name:  our hose crimping machine
Brand: BNTFLEX
Original: China
TRUE FORCE LARGE PRODUCTION HOSE CRIMPERS
BNTFLEX true force production hose crimpers, guarantee that the full rated force of our crimping machines is achieved on every crimp. Unique grease free/true force slide bearing technology have been tested and approved independently to ensure that “1200 tonnes means 1200 tonnes”, proven in the industry!

Main Product

Name: our hose crimping machine
Brand: BNTFLEX
Original: China

AUTOMOTIVE/AEROSPACE HOSE CRIMPERS
BNTFLEX automotive and aerospace hose crimpers are not only the fastest on the China market, but they also totally flexible for brake pipes and work constantly within the tightest tolerances. BNTFLEX hose swaging machines are used 365 days a year to produce thousands of identical parts by many of the biggest names in the motor/aerospace industry.

Main Product

Name: our nut crimper
Brand: BNTFLEX
Original: China

SPECIAL APPLICATION
As the leading Swaging Machine Supplier, BNTFLEX have a dedicated special projects design department. With over 50 years engineering experience BNTFLEX has the knowledge to manufacture special machines for any special applications. To include cable crimping systems, nut crimpers, special test rigs, branded machines and POKAYOKE machine programming. – BNTFLEX covers it all – Hydraulic Hose Workshop, Crimping Machine, Hose Crimping Tool, Swaging Machine, Hose Crimping Machines, Hose Swaging Machine, Swaging Machine Supplier, Hydraulic Hose Crimper and more and more.
Packing & Delivery
Packaging
Size
1070X640X1150mm
Weight
320kg



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

We have more models and products for you choose, like crimping machine range from 1/8-14inches, skiving machine,cutting machine, pipe cutting machine, crimping&skving machine, crimping&skving&cutting machine,hose test machine,pipe bending machine and so on.
