Quick Details

  • Place of Origin: Tianjin, China (Mainland)
  • Brand Name: BNT hydraulic hose
  • Model Number: 1/4" to 2"
  • Product Name: Steel braided reinforced hose Hydraulic Rubber Hose
  • Product Group: hydraulic hose
  • Product Type: air filter hydraulic hose
  • Liner Material: NBR (Nitrile)
  • Cover Material: SBR
  • Reinforcements: 4 braids of high tensile steel wire
  • Outer Cover Colour: black
  • Inner Liner Colour: black
  • Maximum Working Temperature (°c): +100°c (+121°c Intermittent)
  • Minimum Working Temperature (°c): -40°c

Packaging & Delivery

Packaging Details: wrap plastic
Delivery Detail: within 7 days

High Performance wire spiral Hydraulic rubber hose en856 4sh 4sp



EN856 4SH STANDARD

Tube: oil resistant synthetic rubber
Reinforcement: four high tensile steel wire spiral layers (4W/S)
Cover: abrasion and weather resistant synthetic rubber
Temperature range: -40℃ to +100℃



DN

Hose I.D

Wire O.D

Hose O.D

Working Pressure

Burst Pressure

Minimum Bend Radius

inch

mm

mm

mm

Mpa

psi

Mpa

psi

mm

19

3/4"

19.0

28.4

32.0

42.0

6000

168.0

24000

280

25

1"

25.4

35.2

38.6

38.0

5500

152.0

22000

340

32

1-1/4"

31.8

41.9

45.8

32.5

4700

130.0

18800

460

38

1-1/2"

38.1

48.8

53.3

29.0

4200

116.0

16800

560

51

2"

50.8

63.2

68.1

25.0

3600

100.0

14400

700





Barnett offer BNT Hydraulic hose whose products are proven to last up to three times longer than those of other hose manufacturers.

Compact Assemblies: The BNT Hydraulics series hose designed for superior performance at incredible bend radii is an ideal choice for tight, torturous applications.

Total performance: The BNT series with Megaflex CM2T can withstand impulse testing to 600,000 cycles with over 1,000,000 cycles for Multispiral hose and offers reliability and peace of mind as a standard.

Environmental: Hose Hydraulics use environmentally focused technology that is REACH/RoHS/WEEE compliant in the manufacture of our products.



1) Our Hydraulic hose you can get: r1/r2/r3/r7/r8/r12/r9



2)  All hose made By International Standard ( SAE/DIN EN)



3) If you want to save time , we can do assemble the fittings onto the hose







BNT HYDRAULIC HOSE:



 Each of our hydraulic hose are tested strictly before export





Where you can use our hydraulic hose:

One-stop service: Matched hydraulic hose fittings, hose ferrule,hydraulc hose crimping machine, hose cutting machine, hose skiving machine are avaliable.



Any demands, contact me freely
